SOCKET SET SCREWS
SOCKET SET SCREWS
Lorem ipsum dolor sit amet, mauris suspendisse viverra eleifend tortor tellus suscipit, tortor aliquet at nulla mus, dignissim neque, nulla neque. Ultrices proin mi urna nibh ut, aenean sollicitudin etiam libero nisl, ultrices ridiculus in magna purus consequuntur, ipsum donec orci ad vitae pede, id odio.
Lorem ipsum dolor sit amet, mauris suspendisse viverra eleifend tortor tellus suscipit, tortor aliquet at nulla mus, dignissim neque, nulla neque. Ultrices proin mi urna nibh ut, aenean sollicitudin etiam libero nisl, ultrices ridiculus in magna purus consequuntur, ipsum donec orci ad vitae pede, id odio.
Technical Details
| Head Type | HEADLESS |
| Head Profile | STANDARD |
| Drive Style | HEX |
| System of Measurement | INCH |
| Thread Direction | RIGHT HAND |
| Thread Type | INCH |
| Thread Fit | 1/2" BSW |
| Material | ALLOY STEEL |
| Hardness | 45~53 HRC |
| Thread Size | Length | Threading | Min. Thread Length | Thread Spacing | Drive Size | Tensile Strength | Specificaion Met | Grade | Box Qty | PPC | Price/100 (in INR) |
Price/100 (in USD) |
Stock | |
| 1/2" BSW | 1 1/2" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 100 | 8 | 4907 | 62 | 2945 |  |
| 1 1/4" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 100 | 8 | 2115 | 26 | 300 | |
|
| 1" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 100 | 8 | 2114 | 26 | 0 | |
|
| 1/2" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 200 | 8 | 866 | 10 | 4195 | |
|
| 3/4" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 100 | 8 | 1345 | 17 | 2635 | |
|
| 5/8" | F/T | F/T | Coarse | 1/4" | - | BS 2470 | 14.9 | 100 | 8 | 972 | 12 | 0 | |
|
| 1/4" BSW | 1 1/2" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 0 | 1253 | 15 | 0 | |
| 1 1/4" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 0 | 741 | 9 | 0 | |
|
| 1" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 637 | 8 | 6800 | |
|
| 1/2" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 330 | 4 | 6395 | |
|
| 1/4" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 293 | 3 | 43540 | |
|
| 3/4" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 654 | 8 | 2800 | |
|
| 3/8" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 324 | 4 | 8225 | |
|
| 5/16" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 10 | 310 | 3 | 23400 | |
|
| 5/8" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 0 | 430 | 5 | 0 | |
|
| 7/8" | F/T | F/T | Coarse | 1/8" | - | BS 2470 | 14.9 | 200 | 0 | 661 | 8 | 0 | |
|
| M3 | 3mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 90 | 422 | 5 | 95590 | |
| 4mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 90 | 426 | 5 | 477400 | |
|
| 5mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 90 | 432 | 5 | 405315 | |
|
| 6mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 90 | 417 | 5 | 0 | |
|
| 8mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 90 | 423 | 5 | 86375 | |
|
| 10mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 445 | 5 | 32395 | |
|
| 12mm | F/T | F/T | Coarse | A/F 1.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 474 | 6 | 30200 | |
|
| 3/16" BSW | 1/2" | F/T | F/T | Coarse | 3/32" | - | BS 2470 | 14.9 | 200 | 10 | 308 | 3 | 60573 | |
| 1/4" | F/T | F/T | Coarse | 3/32" | - | BS 2470 | 14.9 | 200 | 10 | 246 | 3 | 78800 | |
|
| 3/16" | F/T | F/T | Coarse | 3/32" | - | BS 2470 | 14.9 | 200 | 10 | 254 | 3 | 45200 | |
|
| 3/8" | F/T | F/T | Coarse | 3/32" | - | BS 2470 | 14.9 | 200 | 10 | 268 | 3 | 11200 | |
|
| 5/16" | F/T | F/T | Coarse | 3/32" | - | BS 2470 | 14.9 | 200 | 10 | 260 | 3 | 27600 | |
|
| 3/8" BSW | 1 1/2" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 10 | 2557 | 32 | 3012 | |
| 1 1/4" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 10 | 1287 | 16 | 6475 | |
|
| 1" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 10 | 1180 | 14 | 0 | |
|
| 1/2" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 16 | 502 | 6 | 7428 | |
|
| 3/4" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 16 | 885 | 11 | 0 | |
|
| 3/8" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 16 | 425 | 5 | 19450 | |
|
| 5/8" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 16 | 593 | 7 | 166 | |
|
| 7/8" | F/T | F/T | Coarse | 3/16" | - | BS 2470 | 14.9 | 200 | 16 | 917 | 11 | 0 | |
|
| M4 | 4mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 349 | 4 | 165400 | |
| 5mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 349 | 4 | 151600 | |
|
| 6mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 354 | 4 | 0 | |
|
| 8mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 379 | 4 | 84152 | |
|
| 10mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 385 | 4 | 26394 | |
|
| 12mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 426 | 5 | 209200 | |
|
| 16mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 582 | 7 | 53200 | |
|
| 20mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 707 | 8 | 54200 | |
|
| 25mm | F/T | F/T | Coarse | A/F 2.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 30 | 766 | 9 | 0 | |
|
| 5/16" BSW | 1 1/2" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 400 | 4 | 1836 | 23 | 0 | |
| 1 1/4" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 400 | 4 | 1836 | 23 | 0 | |
|
| 1" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 400 | 4 | 766 | 9 | 4983 | |
|
| 1/2" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 40 | 338 | 4 | 10 | |
|
| 3/4" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 30 | 548 | 6 | 400 | |
|
| 3/8" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 60 | 324 | 4 | 11504 | |
|
| 5/16" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 60 | 310 | 3 | 15326 | |
|
| 5/8" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 40 | 418 | 5 | 0 | |
|
| 7/8" | F/T | F/T | Coarse | 5/32" | - | BS 2470 | 14.9 | 200 | 30 | 706 | 8 | 0 | |
|
| 5/8" BSW | 1 1/2" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 100 | 8 | 8966 | 113 | 0 | |
| 1 1/4" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 100 | 8 | 6649 | 84 | 0 | |
|
| 1 3/4" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 50 | 10 | 8966 | 113 | 0 | |
|
| 1" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 100 | 10 | 3545 | 44 | 50 | |
|
| 2 1/2" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 50 | 8 | 11879 | 150 | 0 | |
|
| 2" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 50 | 10 | 8153 | 103 | 0 | |
|
| 3/4" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 100 | 10 | 2363 | 29 | 0 | |
|
| 5/8" | F/T | F/T | Coarse | 5/16" | - | BS 2470 | 14.9 | 100 | 10 | 2295 | 29 | 758 | |
|
| M5 | 5mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 243 | 3 | 116590 | |
| 6mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 246 | 3 | 4850 | |
|
| 8mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 246 | 3 | 23800 | |
|
| 10mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 268 | 3 | 5215 | |
|
| 12mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 324 | 4 | 7440 | |
|
| 16mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 30 | 376 | 4 | 6684 | |
|
| 20mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 30 | 462 | 5 | 8168 | |
|
| 25mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 20 | 571 | 7 | 2810 | |
|
| 30mm | F/T | F/T | Coarse | A/F 2.5 | 1420 Mpa | DIN 916 | 14.9 | 200 | 20 | 684 | 8 | 3545 | |
|
| M6 | 5mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 482 | 6 | 0 | |
| 6mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 60 | 257 | 3 | 3000 | |
|
| 8mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 280 | 3 | 0 | |
|
| 10mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 316 | 4 | 10878 | |
|
| 12mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 40 | 362 | 4 | 0 | |
|
| 16mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 30 | 463 | 5 | 3175 | |
|
| 20mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 30 | 523 | 6 | 10564 | |
|
| 25mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 20 | 647 | 8 | 4912 | |
|
| 30mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 20 | 853 | 10 | 35065 | |
|
| 35mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 20 | 1307 | 16 | 1054 | |
|
| 40mm | F/T | F/T | Coarse | A/F 3.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 1479 | 18 | 3514 | |
|
| M8 | 6mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 508 | 6 | 0 | |
| 8mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 307 | 3 | 36800 | |
|
| 10mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 326 | 4 | 3000 | |
|
| 12mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 371 | 4 | 1270 | |
|
| 16mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 450 | 5 | 11600 | |
|
| 20mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 584 | 7 | 1314 | |
|
| 25mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 885 | 11 | 7795 | |
|
| 30mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 1070 | 13 | 4185 | |
|
| 35mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 1477 | 18 | 6400 | |
|
| 40mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 10 | 1725 | 21 | 257 | |
|
| 45mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 10 | 1998 | 25 | 0 | |
|
| 50mm | F/T | F/T | Coarse | A/F 4.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 10 | 2271 | 28 | 0 | |
|
| M10 | 8mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 653 | 8 | 675 | |
| 10mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 507 | 6 | 1145 | |
|
| 12mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 16 | 591 | 7 | 0 | |
|
| 16mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 150 | 16 | 787 | 9 | 8293 | |
|
| 20mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 16 | 970 | 12 | 488 | |
|
| 25mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 1341 | 16 | 16998 | |
|
| 30mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 1653 | 20 | 7586 | |
|
| 35mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 2005 | 25 | 2612 | |
|
| 40mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 2283 | 28 | 2926 | |
|
| 45mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 2607 | 33 | 2595 | |
|
| 50mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 3029 | 38 | 913 | |
|
| 55mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 150 | 8 | 4759 | 60 | 0 | |
|
| 60mm | F/T | F/T | Coarse | A/F 5.0 | 1420 Mpa | DIN 916 | 14.9 | 150 | 8 | 5901 | 74 | 0 | |
|
| M12 | 10mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 998 | 12 | 2468 | |
| 12mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 837 | 10 | 22930 | |
|
| 16mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 1002 | 12 | 13147 | |
|
| 20mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 1269 | 16 | 2800 | |
|
| 25mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 10 | 1741 | 22 | 0 | |
|
| 30mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 2014 | 25 | 3600 | |
|
| 35mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 2732 | 34 | 3270 | |
|
| 40mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 3263 | 41 | 2398 | |
|
| 45mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 200 | 8 | 4016 | 50 | 0 | |
|
| 50mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 8 | 4399 | 55 | 110 | |
|
| 55mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 8 | 7567 | 95 | 0 | |
|
| 60mm | F/T | F/T | Coarse | A/F 6.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 8 | 6771 | 85 | 0 | |
|
| M16 | 16mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 2622 | 33 | 528 | |
| 20mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 2950 | 37 | 2684 | |
|
| 25mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 3606 | 45 | 4100 | |
|
| 30mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 4130 | 52 | 3308 | |
|
| 35mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 4965 | 62 | 10 | |
|
| 40mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 5717 | 72 | 0 | |
|
| 45mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 4 | 7055 | 89 | 55 | |
|
| 50mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 8005 | 101 | 45 | |
|
| 55mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 10747 | 136 | 0 | |
|
| 60mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 11242 | 142 | 0 | |
|
| 65mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 16390 | 207 | 0 | |
|
| 70mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 22946 | 290 | 0 | |
|
| 75mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 25674 | 325 | 0 | |
|
| 80mm | F/T | F/T | Coarse | A/F 8.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 4 | 26224 | 332 | 0 | |
|
| M20 | 20mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 7084 | 89 | 0 | |
| 25mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 8203 | 103 | 0 | |
|
| 30mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 9483 | 120 | 0 | |
|
| 35mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 10812 | 136 | 0 | |
|
| 40mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 11651 | 147 | 0 | |
|
| 45mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 100 | 0 | 16840 | 213 | 0 | |
|
| 50mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 0 | 18357 | 232 | 0 | |
|
| 55mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 0 | 20519 | 259 | 0 | |
|
| 60mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 0 | 21804 | 276 | 0 | |
|
| 65mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 0 | 24572 | 311 | 0 | |
|
| 70mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 75 | 0 | 25939 | 328 | 0 | |
|
| 75mm | F/T | F/T | Coarse | A/F 10.0 | 1420 Mpa | DIN 916 | 14.9 | 50 | 0 | 28201 | 357 | 0 | |
